| Model |
HM1500 |
HM3000B |
HM3500A |
| Max. grinding length (mm) |
1500 |
3000 |
3500 |
| Width of working-table (mm) |
180 |
180 |
180 |
| Grinding head motor power (kw) |
4 |
4 |
4 |
| Linear velocity of grinding wheel (m/s) |
15 |
15 |
15 |
| Speed of sliding plate (m/min) |
15.2 |
12/18 |
12/18 |
| Tilting range of working table |
90° |
90° |
90° |
| Overall dimensions (mm) |
3000 x 1000 x 1400 |
5300 x 1250 x 1300 |
5800 x 1350 x 1300 |
| Weight (kg) |
1500 |
2850 |
3200 |
