1.PEDUCER
tHIRD-CLASS DEAD AXEL HELICAL GEAR TRANSMISSION Structure is adopted;gear and tear axel are made of heat treated alloy steel;case and case cover with precise assembly and good seal are made of quality cast iron.The reducer is independent,so it抯 easy to hlad and unload it.
2.Control Box
It has device with up and down stroke protection of break off limiter and can cut off main circuit in an emergency,which ensures safe openation of electric block,Electric elements are of long service life and operational safety.
3.Steel Wire Rope
It usesGB1102-74(6-37+1)hoist steel wire rope which is durable in use.
5.Button Switch
It抯 and-operated,easy to handle ,and has two modes of cord operation and cordless remote control.
paramaters:
|
Mod
el |
Capac
ity
(Ton) |
Clas
sifa
cati
on grade |
Hoist
ing Height
(m) |
Hois
ting Speed
(m/min) |
Runn
ing
speed
(m/min) |
Pulley
ratio |
Lifting
motor Type Power
(kw) |
Running motor Type Power
(kw) |
protec
tion grade |
Type of I-Beam
track |
Loop track minimum radius |
Net.
Weight
(kg) |
|
CD1
MD1
(CD
1Y
MD
1Y)
|
0.5
|
M3
|
6
|
8
8/0.8
|
20
20/6.7
30
30/10
|
2/1
|
ZD21-4
(0.8)
ZDS1-0.2/0.8
(0.2/0.8)
|
ZDY11-4
(0.2)
|
IP44
IP54
|
116a
~
128b
|
1
|
135
|
|
9
|
1
|
140
|
|
12
|
1
|
155
|
|
18
|
1.8
|
175
|
|
24
|
2.5
|
185
|
|
30
|
3.2
|
195
|
|
1
|
M3
|
6
|
8
8/0.8
|
20
20/6.7
30
30/10
|
2/1
|
ZD22-4
(1.5)
ZDS1-0.2/1.5
(0.2/1.5)
|
ZDY11-4
(0.2)
|
IP44
IP54
|
116a
~
128c
|
1
|
180
|
|
9
|
1
|
190
|
|
12
|
1.2
|
205
|
|
18
|
1.8
|
220
|
|
24
|
2.5
|
235
|
|
30
|
3.2
|
255
|
|
2
|
M3
|
6
|
8
8/0.8
|
20
20/6.7
30
30/10
|
2/1
|
ZD31-4
(3)
ZDS1-0.4/3
(0.4/3)
|
ZDY12-4
(0.4)
|
IP44
IP54
|
120a
~
145c
|
1.2
|
250
|
|
9
|
1.2
|
265
|
|
12
|
1.5
|
300
|
|
18
|
2.0
|
320
|
|
24
|
2.8
|
340
|
|
30
|
3.5
|
360
|
|
3
|
M3
|
6
|
8
8/0.8
|
20
20/6.7
30
30/10
|
2/1
|
ZD32-4
(4.5)
ZDS1-0.4/4.5
(0.4/4.5)
|
ZDY12-4
(0.4)
|
IP44
IP54
|
120a
~
145c
|
1.2
|
320
|
|
9
|
1.2
|
340
|
|
12
|
1.5
|
350
|
|
18
|
2.0
|
380
|
|
24
|
2.8
|
410
|
|
30
|
3.5
|
440
|
|
5
|
M3
|
6
|
8
8/0.8
|
20
20/6.7
30
30/10
|
2/1
|
ZD41-4
(7.5)
ZDS1-0.8/7.5
(0.8/7.5)
|
ZDY21-4
(0.8)
|
IP44
IP54
|
125a
~
163c
|
1.2
|
590
|
|
9
|
1.2
|
630
|
|
12
|
1.5
|
650
|
|
18
|
2.0
|
700
|
|
24
|
2.8
|
750
|
|
30
|
3.5
|
800
|
|
10
|
M3
|
6
|
7
7/0.7
|
20
20/6.7
30
30/10
|
2/1
|
ZD51-4
(13)
ZDS1-1.5/13
(1.5/13)
|
2譠DY21-4
(0.8)
|
IP44
IP54
|
140a
~
163c
|
1.5
|
590
|
|
9
|
1.5
|
630
|
|
12
|
1.5
|
650
|
|
18
|
2.5
|
700
|
|
24
|
3.0
|
750
|
|
30
|
4.0
|
