ltem

Parameter

Remark

Main motor power

3kw

Feeding motor power

0.55kw

worm wheel decelerator

50:1 80model

Spindle velocity

4000r/min

Feeding speed

3/5m/min

Double pully gear

Cutting diameter

15-50mm

Select squar section material

Max.cutting quantity

2(semidiameter)mm

Min.working length

400mm

Overall dimension

860x650x980mm

Machine weight

250kg
