The main parameters :

1. Maximum number of disc :6 pieces

2. Maximum diameter of disc:Φ1000mm

3. Maximum vertical stroke: 600mm

4. Working table feeding stroke:2500mm

5. Moving left right stroke:300mm

6. the working table surface area:1700*1200mm

7. Disc elevator speed:525mm/min

8. Maximum working table feeding speed:5920mm/min

9. Total capacity:40.75KW

a. main motor:37 KW

b. vertical motor : 1.5 KW

c. moving left right motor: 0.75KW

d. working table motor:1.5KW

10. Overall dimension:7000(W)*3800(L)*2800mm(H)

11. Weight: 6000Kg
