| Model |
HDP40 |
| Suction,discharge port diameter[mm(in)] |
40(1.5”) |
| Discharge capacity(m3/h) |
10 |
| Discharge capacity(m3/h) |
42(137.79) |
| Max suction head[m(ft)] |
8(26.25) |
| Rotation speed(rpm) |
3600 |
| Priming time(s/4m) |
40 |
| Overall dimension(LxWxH)[mm(in)] |
570x445x550(22.44x17.52x21.65) |
| Dry weigt[kg(ibs.) |
46(101.2) |
| Engine model |
178F |
| Rated power[kW(hp)] |
3.7(5.03) |
| Rated rotation speed(rpm) |
3600 |
| Displacement[ml(cu,in)] |
296(18.06) |
| Fuel tank capacity[L(gal.)] |
4.0(5.44) |
| Fuel consumption[g(ml)kW.h] |
285(339) |
