HXDG5000CL diesel engine generator
NEXT Mobile type generating sets Back List PRE 2.5QF-3 GASOLINE GENERATOR




Rated frequency [Hz]:50  60
Rated voltage [V]:232
Rated current [A]:18.3 19.2/38.4
Rated output power [KVA]:4.2 4.6
Max output power [KVA]:4.5 5.0
Rated rotation speed [rpm]:3000 3600
DC output:12V 8.3A
Power factor [cos]:1
Phase number:Single phase
Noise level [dB(A)@7m]:84-85
Overall dimension (LxWxH) [mm ]:740x500x660
Dry weight [kg]:95 recoil 100 electric
Structure type:Open-frame type
Excitation mode:Self-excitation brushless
Engine model:SH186F/E
Engine type :Single cylinder, 4-stroke, air-cooled,
 direct injection, diesel engine
Displacemen [ml (cu.in)]:406 (24.78)
Compression ratio :19:01:00
Rated power [KW (Hp)/rpm]:5.7 (7.64)/3000 6.3 (8.45)/3600
Starting system:CL:recoil starter E:electric starter
Rotation dircetion (View from flywheel)
Fuel:0# (summer) or -10# (winter) light diesel
Lube:SAE10W30 (above CC grade)
Low oil pressure alert system:With
