DESCRIPTION:
Type: 4 x 4 wheeled
Constructional weight:3,940kg
Wheel base:2,385mm
Max. traction force:33kn
Front wheel tread:1,630-1,960mm
Rear wheel tread:1,504-2,074mm
Engine type:DEUTZ 226B-4T2
Rated revolution:2,400r/min
Rated power:59kw
Front wheel tire:11.2-28mm
Rear wheel tire:16.9-34mm
Clutch type:LUK Single disk, dry-type, independent operation, two-stage
Gear box:27 forward gear,9 reverse gear (with creeper)
Brake assembly:Foot controlled, hydraulic operating, single disk
Speed of P.T.O.(r/min):Independent type:540&1000,ratio of synchronous P.T.O. & driving wheel:5.455&8.971 |
