Functions: Sugarcane cultivating and ridge, plough, rotary tilling, harrowing, reaping, etc.

Application scope: Sugarcane field, vegetable gardens, etc.

Model

3ZP-0.6

 Specification items

Style

Single axle, wheel, tractor,

Depth(mm) of working

≧60

Overall dimensions

2200×780×1030(mm)

Height(mm) of earthing up

≧40

Wheel base

400～600(mm)

Min.ground clearance

159(mm)

Rate of breaking earth

≧80

Weight

235(KG)

Working efficiency(km/h)

≧1.5

Min.turning semidiameter

≤1.7(m)

Oil consumption(L/hm2)

≧14.0

Engine model

 R180

Rated power

5.67(KW)
