Model |
JC170 |
JC175 |
|
Type |
Single-cylinder Four-stroke |
|
Combustion system |
Swirlcombustion Chamber |
|
Bore×stroke(mm) |
70×70 |
75×70 |
|
Compression ratio |
22±1 |
22±1 |
|
1-hour rated output(kw/r/min) |
3.64/2600 |
4.0/2600 |
|
12-hour rated output(kw/r/min) |
3.31/2600 |
3.68/2600 |
|
Specific fuel consumption(g/kw.h) |
≤284.2 |
≤284.2 |
|
Specific lube oil consumption(g/kw.h) |
≤4.76 |
≤4.76 |
|
Cooling system |
Hopper water- cooled |
|
Lubrication system |
Combined pressure and Splashing |
|
Starting method |
Hand crank |
|
Net weight(kg) |
48 |
48 |
|
Method of power output |
Output of flywheel end |
|
Overall dimensions (L×W×H)(mm) |
495×312×415 |
495×312×415 |
